主机型号：1

发电机型号：1

发电机功率：1KW

1.本船的主尺度如下：Principal Dimensions of the Vessel: 总 长 Overall Length: 128.60m 垂线间长 Length Between Perpendiculars: 117.20m 型 宽 Molded Width 22.00m 型 深 Molded Depth: 8.80m 设计吃水 Design Draft: 6.25m 作业吃水(挖泥状态) Operating Draft (Dredging Condition): 7.90m 定 员 Crew Capacity: 34P 主机功率 Main Engine Power: 2 台(Units) DN8330ZC2 4045kW×650rpm×2 艏侧推 Bow Thruster: 600KW×1 台(Unit) 2 航速 Speed: ~14.60kn（6.25m） 船级 Classification Society: CCS 2. 总体及作业性能 General and Operational Performance — 最大装载舱容 9000m³、自卸、带艏吹艏喷耙吸挖泥船 — Maximum loading hopper capacity: 9000m³, self-unloading, with bow blowing and bow spraying functions — 单甲板钢质全焊接、尾楼甲板室顶部设驾驶室 —Single-deck, all-steel welded structure; wheelhouse located on top of the poop deckhouse — 双机、双螺旋桨、双舵、电动艏侧推器 — Twin engines, twin propellers, twin rudders, electric bow thruster —最大挖深（空载吃水以下）：左耙：35m/40m；右耙：35m/40m/50m/60m/75m — Maximum dredging depth (below light draft): Left rake: 35m/40m; Right rake: 35m/40m/50m/60m/75m — 吸／排管直径:900mm/850mm — Suction/Discharge Pipe Diameter: 900mm/850mm —左耙采用三套吊架，即弯头吊架、耙中吊架、耙头吊架； — Left rake is equipped with three sets of hangers: elbow hanger, middle rake hanger, and rake head hanger; 右耙 35m/40m/50m/60m 挖深采用三套吊架，即弯头吊架、耙中吊架、耙头吊架； Right rake for 35m/40m/50m/60m dredging depth uses three sets of hangers: elbow hanger, middle rake hanger, and rake head hanger; 右耙 75m 挖深采用四套吊架，即弯头吊架、耙中吊架、水下泵吊架、耙头吊架； Right rake for 75m dredging depth adopts four sets of hangers: elbow hanger, middle rake hanger, submersible pump hanger, and rake head hanger; — 开口泥舱，配二列共 12 只￠3200mm 锥形泥门,配二列 CHERRY 13823383044
